Release News - ESATAN-TMS 2020 is now released

ESATAN-TMS 2020 is now available to download from our website. ESATAN-TMS provides a high-productivity and powerful thermal modelling environment, supporting the complete thermal analysis process from geometry creation, radiative and thermal analysis, and post-processing of the thermal results.


For a full description of all the functionalities and improvements, please read the Release Notes


ESATAN-TMS 2020 features are outlined below:


Definition of properties of faces and volumes

  • Ability to set the properties such as opticals, node numbers, colour ... of individual faces and volumes.

Custom cavities and cavities defined by face

  • Ability to define a cavity per face rather than surface as well defining a custom cavity or modifying a generated one.

Remove shell face

  • Ability to remove directly selected shell faces of a geometry rather than having to define a cut geometry. Simple mechanism provided to select and remove one or more shell face.

Export of variables to analysis file

  • ESATAN-TMS allows a fully parametrised model to be defined, allowing a clear and maintainable model to be created. Extending this capability, ESATAN-TMS 2020 provides the ability to retain references to parameters within the generated thermal model.

Post-Processing - Charting of radiative case heat fluxes

  • Ability to chart environment heat fluxes directly from the radiative case using charts, delta charts as well as limits charts.

Post-Processing - Charting of thermal user constants

  • User-defined or automatically generated User Constants can be post-processed in Workbench using charts.
